Flat Fluid

Files: FlatFluid.shader

Path: "CGF/Shaders/FlatLighting"

Shader menu: "CG Framework/Flat Lighting/Flat Fluid"

Description

Unity shader CG Framework/Flat Lighting/Flat Fluid.

Reference

• Fluid Type – Fluid Type properties.
  • Fluid Type – Type of surface of the fluid.
    • Smooth – Selects the Smooth option.
    • Flat – Selects the Flat option.
• Wave Movement – Wave Movement properties.
  • Wave Movement – Sine wave vertex movement.
  • Wave Frequency – Frecuency of the waves.
  • Wave Amplitude – Amplitude of the waves.
  • Wave Direction – Direction of the wave movement.
  • Wave Speed – Speed of the wave movement.
  • Wave Noise Map (R) – Map for an additional height displacement of the vertex.
  • Wave Noise Level – Level of the additional height displacement.
  • Wave Noise Scroll – Scroll speed of the additional height displacement.
• Foam – Foam properties.
  • Foam – Foam on mesh intersection.
  • Foam Texture (RGB) – Texture applied on the foam area.
  • Foam Texture Scroll – Scroll of the foam texture.
  • Foam Texture Level – Level of the foam texture.
  • Foam Texture Smooth – Smooth of the edge of the foam texture.
  • Foam Texture Reverse – If enabled, reverse the foam texture color.
  • Foam Texture Blending – If enabled, blend the foam texture color.
  • Foam Color (RGBA) – Foam color.
  • Foam Falloff – Fallof value.
  • Foam Distance – Foam length.
  • Foam Level – Level of the color based on the source color.
• Water Depth – Water Depth properties.
  • Water Depth – Water depth effect.
  • Shallow Color – Color of the shallow part of the water.
  • Shallow Light – Brightness of the shallow part of the water.
  • Use Base Color – If enabled, use the base color as a shallow color.
  • Water Depth Falloff – Fallof value of the depth.
  • Water Depth Distance – Length value of the depth.
• Refraction – Refraction effect.
• Refraction Map (RG) – Refraction Map (RG).
• Refraction Level – Refraction Level. X value is for the level of the first refraction map copy and Y is for the level of the second refraction map copy.
• Refraction Scroll – Scroll the refraction texture. XY value is for the scroll of the first refraction map copy and ZW is for the scroll of the second refraction map copy.
• Reflection – Reflection properties. See Common Features / Reflection.
• Light Colors – Light Colors by normal direction. See Common Features / Light Colors.
• Light Textures – Light Textures by normal direction. See Common Features / Light Textures.
• Alpha cutoff – Alpha cutoff.
• Front Gradient – Front color gradient. See Common Features / Front Gradient.
• Right Gradient – Right color gradient. See Common Features / Right Gradient.
• Top Gradient – Top color gradient. See Common Features / Top Gradient.
• Back Gradient – Back color gradient. See Common Features / Back Gradient.
• Left Gradient – Left color gradient. See Common Features / Left Gradient.
• Bottom Gradient – Bottom color gradient. See Common Features / Bottom Gradient.
• Gradient Steps – Shading steps of the gradient.
• Height Fog – Height Fog properties. See Common Features / Height Fog.
• Distance Fog – Distance Fog properties. See Common Features / Distance Fog.
• Light – Light properties.
  • Light – Light and Ambient light.
  • Light – Light and Ambient light.
  • Directional Light – If enabled the color of the main directional light affect to the source mesh.
  • Ambient Light – If enabled ambient light affect to the source mesh.
• UV Scroll – UV Scroll properties. See Common Features / UV Scroll.
• Stencil Options – Stencil Options properties. See Common Features / Stencil Options.
• Stencil Comparison Function – Stencil Comparison Function.
• Stencil Pass Operation – Stencil Pass Operation.
• Stencil Fail Operation – Stencil Fail Operation.
• Stencil ZFail Operation – Stencil ZFail Operation.
• Blend Mode – Blend Mode.

Use

Assign the shader from CG Framework/Flat Lighting/Flat Fluid to a material.
Configure the grouped material properties listed in Reference from the Unity material inspector.
